Jinko Solar Hybrid Inverter 10kW 3 Phase

Jinko Solar Hybrid Inverter JKS-10K-SG04LP3-EU is 10kW 3Phase LV Battery compatible system.

Key Features:

Future conception for solar
Charge controller and inverter integrated
Intelligent battery management function
Capable of being grid-interactive or grid-independent
More security & performance for same costs
Battery max. discharge power up to 10 kW
Monitoring inverters freely via computers or mobile phones
Back-Up Mode can integrate with diesel generator

Specifications:
Product Type Hybrid Inverter
Enclosure IP65
Ambient Temperature -45ºC ~ 60ºC (>45ºC derating)
Protection Level Class I
Charge Mode
Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c)
Battery Current 210Ad.c (max.)
AC Input Voltage 3L/N/PE 220/380Va.c, 400Va.c
AC Input Frequency 50/60Hz
AC Input Rated Current 15.2Aa.c
Max. AC Input Current 22.7Aa.c (max.)
Max. AC Input Power 11000W
Max. Apparent Output Power 11000VA
PV Input Voltage 550Vd.c (160Vd.c ~ 800Vd.c)
MPPT Input Voltage 200Vd.c ~ 650Vd.c
PV Input Current 26Ad.c + 13Ad.c
Max. PV Input Power 13000W
Max. PV Isc 34Ad.c + 17Ad.c
Utility-Interactive
AC Output Voltage 3L/N/PE 220/380Va.c, 400Va.c
AC Output Frequency 50/60Hz
AC Output Rated Current 15.2Aa.c
Max. AC Output Current 22.7Aa.c (max.)
Max. AC Output Power 11000W
AC Output Rated Power 11000W
AC Output Power Factor 0.95 leading to 0.95 lagging
Max. AC Isc 75Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Battery Discharge Current 210Ad.c (max.)
Battery Discharge Power 10000W
Stand Alone
AC Output Voltage 3L/N/PE 220/380Va.c, 400Va.c
AC Output Frequency 50/60Hz
AC Output Rated Current 15.2Aa.c
AC Output Rated Power 10000W
Max. Continuous AC Pass-through
Current 45Aa.c
Peak Output Power 20000W (10 seconds)
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Max. Discharge Current 210A (max.)
